DN50mm-800mm(2''-32'') Pneumatic Actuator Operated Butterfly Valve 2 Way Butterfly Valve

DN50mm-800mm(2''-32'') Pneumatic Actuator Operated Butterfly Valve 2 Way Butterfly Valve

Products - Water Treatment Equipment - Butterfly Valve
  • Highlight

    DN50mm Butterfly Valve

    ,

    DN800mm 2 Way Butterfly Valve

    ,

    pneumatic butterfly valve odm

  • Product Name
    Butterfly Valve With Pneumatic Actuator Working
  • Type
    Two Way Butterfly Valve
  • Port Size
    DN50mm-800mm(2''-32'')
  • Standard
    GB2555-81, GB4216-84, IS02084-1974
  • Place of Origin
    China

DN50mm-800mm(2''-32'') Pneumatic Actuator Operated Butterfly Valve 2 Way Butterfly Valve

  • DN50mm-800mm(2''-32'') Pneumatic Actuator Operated Butterfly Valve 2 Way Butterfly Valve
  • DN50mm-800mm(2''-32'') Pneumatic Actuator Operated Butterfly Valve 2 Way Butterfly Valve
Get Price Contact Now

DN50mm-800mm(2''-32'') Pneumatic Actuator Operated Butterfly Valve 2 Way Butterfly Valve



Pneumatic Butterfly Valve Main Features
1. Small in size and light in Weight and easy maintenance, It can be mounted wherever needed.
2. Simple, compact structure, quick 90 degree on -off operation.
3. Disc has two -way bearing, perfect seal without leakage under the pressure test.
4. Flow curve tending to straight-line, Excellent regulation performance
5. Center plate structure, small torque of open and close.
6. Long service life, Standing the test of ten thousand opening and closing operation.
7. Can be used in cutting off and regulating media.



Pneumatically Operated Butterfly Valve Specification

规格 H1 H2 H3 S φ 法兰式L 伸缩最大长度Lmax 伸缩最大长度Lmin 伸缩设计长度L L1 L2 L3 n-d-M 气动装置型号
mm inch
50 2 80 112 156 88.4 125 108 163 138 151 89 181 105 4-18-M16 TAG09
65 21/2 95 122 156 102.5 145 112 188 152 170 89 181 105 4-18-M16 TAG09
80 3 98 130 156 113.1 160 114 192 165 177 89 181 105 8-18-M16 TAG09
100 4 114 142 214 68.9 180 127 215 175 205 110 222 132 8-18-M16 TAG11
125 5 128 174 214 80.4 210 140 230 185 215 110 222 132 8-18-M16 TAG11
150 6 139 180 214 91.8 240 140 240 195 225 110 222 132 8-22-M20 TAG11
200 8 175 225 224 112.9 295 152 265 215 245 148 257 156 8-22-M20 TAW13
250 10 215 266 285 90.6 350 165 295 235 260 290 590 136 12-22-M20 TAW13
300 12 245 290 285 103.5 400 178 302 252 282 290 290 133 12-22-M20 TAW13
350 14 270 320 285 89.7 460 190 321 271 301 290 290 133 16-22-M20 TAW13
400 16 305 400 381 100.5 515 216 333 283 313 378 387 175 16-29-M24 TAW17
450 18 325 425 381 88.4 565 222 354 304 334 378 387 175 20-26-M24 TAW17
500 20 260 480 381 97 620 229 366 316 346 378 387 175 20-26-M24 TAW17
600 24 44 520   113.4 725 267 418 368 398       20-30-M27
700 28 5505 582   109.6 840 292 445 395 425       24-30-M27
800 32 560 620   124 950 318 475 725 455       24-33-M30

Note:
1. The pneumatic device equipped with DN600-800 butterfly valve requires special ordering
2. The flange connection dimensions in the table all comply with GB2555-81, GB4216-84, IS02084-1974
3. The original design length of the telescopic butterfly valve in the table can be lengthened according to the user's needs. Its maximum length and minimum length will change equally with the change of the required design length.
4. The size of the electric device part of the 0.6Mpa and 1.6Mpa pressure level electric flange telescopic (flange) butterfly valve is the same as the 1.0Mpa pressure level size in the above table.
5. If the size of the pneumatic device changes, please refer to the size of the random sample shipped.

DN50mm-800mm(2''-32'') Pneumatic Actuator Operated Butterfly Valve 2 Way Butterfly Valve 0

Application:
DN50mm-800mm(2''-32'') Pneumatic Actuator Operated Butterfly Valve 2 Way Butterfly Valve 1
