Steel Structure FRP Counterflow Cooling Tower Open Circuit Cooling Tower
Product Classification (inlet and outlet water temperature difference):
1. Standard type: the inlet water temperature t1:=38℃, the outlet water temperature t2=32℃, and the temperature difference △t=6℃
2. Medium temperature type: the inlet water temperature t1=43℃, the outlet water temperature t2=33℃, and the temperature difference △t=10℃
3. High temperature type: the inlet water temperature t1=60℃, the outlet water temperature t2=35℃, and the temperature difference △t=25℃
Product Specification:
| type |
water capacity m³/h |
single tower size |
fan |
water distribution system |
weight |
Standard point noise dB A |
size |
||||||||
| W((mm) |
H(mm) |
air volume x 10*4m³/h |
diameter (mm) |
motor power kw |
water inle pipe DN |
t H(mm) |
inlet wate pressure KPa |
dry t |
wet t |
h, mm |
h2 mm |
L5 mm |
|||
| GNZF-1000 |
1000 |
8400 |
9350 |
66.4 |
6000 |
45 |
500 |
5150 |
62.2 |
27.2 |
45.2 |
≤75 |
6350 |
800 |
1050 |
| GNZF-1500 |
1500 |
10200 |
10520 |
99.6 |
7000 |
75 |
600 |
5590 |
66.5 |
38.4 |
54.4 |
≤75 |
6790 |
800 |
1280 |
| GNZF-2000 |
2000 |
11800 |
11190 |
132.7 |
8000 |
90 |
700 |
5690 |
67.5 |
41.6 |
62.6 |
≤75 |
7190 |
900 |
1500 |
| GNZF-2500 |
2500 |
13200 |
11870 |
165.9 |
8530 |
110 |
800 |
5990 |
70.5 |
45.8 |
71.7 |
≤75 |
7540 |
1000 |
1650 |
| GNZF-3000 |
3000 |
14400 |
12740 |
199.1 |
8530 |
132 |
900 |
6410 |
74.6 |
58.2 |
88.4 |
≤75 |
8410 |
1000 |
1800 |
| GNZF-3500 |
3500 |
15600 |
13640 |
229.2 |
8530 |
160 |
900 |
6810 |
78.5 |
66.9 |
102.5 |
≤75 |
9310 |
1000 |
1500 |
| GNZF-4000 |
4000 |
16560 |
13940 |
263.0 |
9140 |
185 |
1000 |
7110 |
81.4 |
76.4 |
112.8 |
≤75 |
9610 |
1200 |
1500 |
| GNZF-4500 |
4500 |
17760 |
14640 |
294.7 |
9140 |
220 |
1000 |
7310 |
83.5 |
87.8 |
129.6 |
≤75 |
10310 |
1200 |
1500 |
|
design condition: db temp=31.5℃ wb temp=28℃ note: 1.every foundation level is same,with a tolerance of ±2mm, barometric pressure=1.0004 x10*5Pa and the allowed center deviation is±2mm inlet water temp=43℃ outlet water temp=33℃ 2.the tower column and embedded steel plate position welding directly |
|||||||||||||||
Product Feature:
The new high-efficiency counter flow cooling tower has the characteristics of high efficiency, energy saving, no drifting water, low noise, small footprint, low cost, fire prevention, corrosion resistance, and long life.
HLT Counterflow Cooling Tower is a brand-new optimized design based on the original square countercurrent tower. Its advantages are:
1. Water distribution system: It adopts fixed large-caliber nozzles, and uses the water pump's own pressure water to splash into mist. The nozzles are not blocked, which solves the problem of water distribution by the booster effect of the old product nozzles. The nozzles are easily blocked and broken. Use large-caliber nozzles to reduce maintenance costs.
2. Tower wall panels: The surrounding wall panels are made of double-layer sandwich insulation panels, fiberglass wall panels and stainless steel wall panels.
3. Water collector: It adopts active interlaced water collectors, which are simple and convenient to maintain and have good water collection. It has the characteristics of small wind resistance and extremely low drift loss.
4. Easy combination: Users can select and combine according to the installation site. They can be combined with large-tonnage towers or small-tonnage towers into large-tonnage tower groups.
Frequency converter: The use of frequency converter can save 35%-45% of electricity. It automatically adjusts the speed of the fan with the change of ambient temperature or water temperature, and automatically turns on and off when the set temperature is reached. (Configured according to user needs)
Our products are sold all over the world, you can rest assured.
